Product Detail:
1. The video coding format for the second generation h. 264, coding total resources 400 frames, 4 D1 + 12 CIF real-time video. 16 Channel audio synchronization, 16 Channel independent alarm input. Support 6 (video playback, work, the cell phone, monitoring, net menu operation, backup) operation, support single D1 or 16 Channel CIF synchronous replay.
2. Network function is very good, the built-in PPPOE agreement and dynamic domain name; Support UPNP, automatic port mapping; Support electronic amplification; Preview the paint of paint, etc. Support free domain name, the most simple set of networking
3. Three streaming technology (video, CIF nets pass, QCIF phone network),support the mobile phone monitoring, able to as your wishes,the all things under your control.
4. USB 2.0 backup, direct by U disk or USB hard drive to backup.
5. Human interface, and USB mouse flexible operation; Support HDMI HD output .
6. Four SATA hard disk interface. Support a single biggest 2 T hard disk. Optional ring on.
Specification:
| Item |
Device Parameter |
Specification |
| System |
Language |
English/ Chinese |
| GUI |
Graphic menu(OSD Menu) |
| password |
user password, administrator password |
| Video |
Video in |
16 ch composite video input 1.0Vp-p,impedance75¦¸,BNC |
| Video out |
2ch composite video output 1.0Vp-p,impedance75¦¸,BNC |
| Video display |
16ch:1/4/9/16channel switch |
| Video standard |
PAL,25f/s,CCIR625line,50scene |
| ˇˇ |
| NTSC,30f/s,CCIR525line,60scene |
| Audio |
Audio input |
16ch audio input,impedance600¦¸,RCA |
| Audio output |
1ch audio output,impedance600¦¸,RCA |
| Basic electricity output |
Linearity electricity |
| Record style |
Audio video recorded simultaneously |
| Audio compression |
ADPCM |
| Picture proceeding and store |
Picture compression |
H.264 |
| Picture resolution |
CIF |
| Streaming style |
ISO14496-10 |
| Audio style |
ADPCM |
| Video code rateˇˇˇˇ |
CIF: 384,512,768 Kbps Standard(optional) |
| HD1:512,768,1024Kbps Higher(optional) |
| D1:896,1024,1280Kbps The highest (optional) |
| Audio code rate |
32KB/s |
| Data storage |
SATA HDD storage(optional) |
| Alarm |
Alarm input |
16 alarm input |
| Alarm output |
1 alarm output |
| Connector |
Serial interface |
Support 1 RS5 |
| ˇˇ |
| Support 1 RS485 |
| Network interface |
RJ45,10M/100M |
| VGA |
VGA output |
Support 800x600,1024x768,1280x1024,1366x768, |
| ˇˇ |
| 1440 x900 resolution |
| HDMI |
HD Video output |
Support720P,1080I,1080P |
| Supporting software |
IE software |
Through the cable network realization video preview, video downloads, configuration parameters etc Functions |
| Software upgrade |
Support USB firmware upgrade |
| others |
Voltage input |
AC:110~240V |
| Power Consumption |
6W without HDD |
| Working temperature |
-10----50ˇć |
