Specifications:
1. Using the latest h.264 compression algorithm, compression rate is high.
2. Support 4ch audio and video surveillance video, support CIF, English, D1 resolution.
3. Support compound flow and streaming video coding, composite stream audio and video coding in sync.
4. Support the watermark function.
5. Support HD VGA and BNC and output
6. Support free domain name, the most simple set of networking
7. Support mainstream PTZ decoder control protocol, support the preset point, cruise path and track
8. To support a SATA hard drive, can support capacity is not less than 2 TB hard drive.
9. Support the mainstream of the operating system into intelligent mobile phone, and cell phones can store several IP address on demand.
Technology parameters:
| Item |
Device Parameter |
Specification |
| System |
Language |
English/ Chinese |
| GUI |
Graphic menu(OSD Menu) |
| password |
user password£¬ administrator password |
| Video |
Video in |
4/8ch composite video input 1.0Vp-p£¬impedance75¦¸£¬BNC |
| Video out |
1ch composite video output£¬BNC£¨4 CH£© 1ch composite video output£¬BNC£¨8 CH£© |
| Video display |
4ch:1/4channel switch(8channel:1/4/9 channel ) |
| Video standard |
PAL£¬25f/s£¬CCIR625line£¬50scene NTSC£¬30f/s£¬CCIR525line£¬60scene |
| Audio |
Audio input |
4/8ch audio input£¬impedance600¦¸£¬RCA |
| Audio output |
1ch audio output£¬impedance600¦¸£¬RCA |
| Basic electricity output |
Linearity electricity |
| Record style |
Audio video recorded simultaneously |
| Audio compression |
ADPCM |
| Picture proceeding and store |
Picture compression |
H.264 |
| Picture resolution |
CIF/HD1/D1 |
| Streaming style |
ISO14496-10 |
| Audio style |
ADPCM |
| Video code rate |
CIF: 384~768 Kbps(optional) HD1:512~1024Kbps(optional) D1:512~1024Kbps(optional) |
| Audio code rate |
32KB/s |
| Data storage |
SATA HDD storage(optional) |
| Alarm |
Alarm input |
4/8 alarm input |
| Alarm output |
1 alarm output |
| Connector |
Serial interface |
Support 1 RS485 |
| Network interface |
RJ45£¬10M/100M |
| VGA |
VGA output |
Support 800x600,1024x768,1280x1024,1366x768, 1440 x900 resolution |
| Software upgrade |
Support USB firmware upgrade |
| others |
Voltage input |
AC:110~240V |
| Power Consumption |
6W without HDD |
| Working temperature |
-10----50¡æ |
All products Warranty
- Brand New!
- Full 1 year replacement warranty & 30 days money back guarantee!
- This product is helpful for you and your home safety and saving your money
|
