The WV-CF374 Series colour surveillance camera includes a newly developed Digital Signal Processor (DSP), providing improved image quality in a cost-effective unit.
Utilising the revolutionary Adaptive Black Stretch technology, the DSP uses image processing to automatically detect dark areas inside an image, applying the most suitable gamma correction curve for darker areas. This image processing algorithm transforms shadows and dark areas into natural and crisp images in real time like never before.
Horizontal resolution is 650 TV lines in colour mode and due to the new DSP and the introduction of a new circuit, minimum illumination intensity is made possible at 0.08 lux in colour mode and 0.008 lux in black & white.
* High performance digital signal processor
* Superb image quality and cost performance
* Adaptive Black Stretch technology
* True Day/Night operation can be selected automatically or manually
* 2.8 ~ 10 mm 3.6x Varifocal Auto Iris lens
|
| TV System |
PAL |
| Camera |
Image Sensor |
1/3 type interline transfer CCD |
| Effective Pixels |
976 (H) x 582 (V) |
| Scanning Mode |
2:1 interlace |
| Scanning Area |
4.8 (H) x 3.6 (V) mm |
| Scanning Frequency |
Horizontal: 15.625 kHz |
| Vertical: 50.00 Hz |
| Horizontal Resolution |
650 TV lines |
| Minimum Illumination |
Color: 0.08 lx (Sens Up: Off, AGC: High) |
| B/W: 0.008 lx (Sens Up: Off, AGC: High) |
| Signal-to-Noise Ratio |
52 dB (AGC: OFF) |
| White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 8,000 K), |
| ATW2 (2,400 ~ 8,000 K) |
| Light Control |
ALC/ALC+/EL |
| AGC |
ON (LOW, MID, HIGH) / OFF |
| Electronic Shutter |
OFF (1/50), AUTO, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, |
| 1/4,000, 1/10,000 |
| Electronic Sensitivity UP |
32x max. AUTO, 512x max. FIX |
| Day & Night |
y & Night (IR) Off / Auto1 /Auto2 / On |
| Digital Noise Reduction |
High or Low |
| Scene File |
2 patterns |
| Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
| Privacy Zone |
ON (1) / ON (2) / OFF, up to 8 zones |
| Auto Image Stabilizer |
ON / OFF |
| Camera Title |
16 alphanumeric characters |
| Synchronization |
Internal (INT) |
| Lens |
Focal Length |
2.8 mm ~ 10.0 mm |
| Zoom Ration |
3.6x |
| Angular Field of View |
27.6¡ã (Tele) ~ 100.8¡ã (Wide), V: 20.7¡ã (Tele) ~ 73.8¡ã (Wide) |
| Maximum Aperture Ratio |
1:1.3 (Wide) ~ 3.0 (Tele) |
| Focusing Range |
0.3 m (0.98 ft.) ~ ¡Þ |
| Input/ Output |
Video Output |
1.0 V [p-p] / PAL composite 75 |
| Controller Interface |
Coaxial Multiplex System |
| General |
Setup Method |
OSD setup menu |
| Password Lock |
All menus |
| Language |
English, Russian, German, French, Italian, Spanish, Chinese, |
| Japanese |
| Safty/EMC Standard |
CE (EN55022 ClassB, EN55024), GOST (GOST R 51558) |
| Power Source and |
12 V DC, 180 mA / 24 V AC, 50 Hz, 2.1 W |
| Power Consumption |
| Ambient Operating Temperature |
¨C10 ¡ãC ~ +50 ¡ãC (14 ¡ãF ~ 122 ¡ãF) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
| Dimensions |
ø108 x 94 mm (H) (ø4-1/4" x 3-3/4" (H)) |
| Mass (approx.) |
320G |
| Finish |
ABS resin / Sail White |
